LRS SERIES
LRS-35-24V
LRS-35-24V
LRS-35-24V
Output
- Rated Power: 35W
- Rated Current: 1.5A
- DC Voltage: 24V
- Voltage Tolerance: +1.0%
Input
- Voltage Range: 85~264VAC 120-373VDC
- Efficiency (Typ): 89%
- Dimension (mm): 99 x 82 x 30
LRS-50-24V
LRS-35-24V
LRS-35-24V
Output
- Rated Power: 52.8W
- Rated Current: 2.2A
- DC Voltage: 24V
- Voltage Tolerance: +1.0%
Input
- Voltage Range: 85~264VAC 120-373VDC
- Efficiency (Typ): 88%
- Dimension (mm): 99 x 82 x 30
LRS-75-12V
LRS-35-24V
LRS-75-12V
Output
- Rated Power: 75W
- Rated Current: 6A
- DC Voltage: 12V
- Voltage Tolerance: +1.0%
Input
- Voltage Range: 85~264VAC 120-373VDC
- Efficiency (Typ): 89%
- Dimension (mm): 99 x 97 x 30
LRS-75-24V
LRS-100-24V
LRS-75-12V
Output
- Rated Power: 75W
- Rated Current: 6A
- DC Voltage: 24V
- Voltage Tolerance: +1.0%
Input
- Voltage Range: 85~264VAC 120-373VDC
- Efficiency (Typ): 89%
- Dimension (mm): 99 x 97 x 30
LRS-100-24V
LRS-100-24V
LRS-100-24V
Output
- Rated Power: 108W
- Rated Current: 4.5A
- DC Voltage: 24V
- Voltage Tolerance: +1.0%
Input
- Voltage Range: 85~264VAC 120-373VDC
- Efficiency (Typ): 88%
- Dimension (mm): 129 x 97 x 30
LRS-150-12V
LRS-100-24V
LRS-100-24V
Output
- Rated Power: 150W
- Rated Current: 12.5A
- DC Voltage: 12V
- Voltage Tolerance: +1.0%
Input
- Voltage Range: 85~132VAC 170-264VDC
- Efficiency (Typ): 87.5%
- Dimension (mm): 160 x 98 x 30
LRS-150-24V
LRS-150-24V
LRS-150-24V
Output
- Rated Power: 156W
- Rated Current: 6.5A
- DC Voltage: 24V
- Voltage Tolerance: +1.0%
Input
- Voltage Range: 85~132VAC 170-264VDC
- Efficiency (Typ): 89%
- Dimension (mm): 160 x 98 x 30
LRS-200-24V
LRS-150-24V
LRS-150-24V
Output
- Rated Power: 204W
- Rated Current: 17A
- DC Voltage: 24V
- Voltage Tolerance: +1.5%
Input
- Voltage Range: 90~132VAC/ 180-264VDC by switch 240~370VDC (switch on 230 VAC)
- Efficiency (Typ): 89%
- Dimension (mm): 216 x 115 x 30
LRS-350-12V
LRS-150-24V
LRS-350-12V
Output
- Rated Power: 350W
- Rated Current: 0~14.6A
- DC Voltage: 12V
- Voltage Tolerance: +1.5%
- Dimension (mm): 215 x 115 x 30
LRS-350-24V
LRS-350-24V
LRS-350-12V
Output
- Rated Power: 350W
- Rated Current: 0~14.6A
- DC Voltage: 24V
- Voltage Tolerance: +1.5%
- Dimension (mm): 215 x 115 x 30
LP SERIES
LPH-18W-12V
LPH-18W-12V
LPH-18W-12V
Output
- Rated Power: 18W
- Rated Current: 1.5A
- DC Voltage Range: 12V
- Voltage Tolerance: +3.0%
Input
- Voltage Range: 180 ~ 264VAC 254~370VDC
- Efficiency(Typ): 77%
- Dimension (mm): 140 x 30 x 22
LPV-20W-12V
LPH-18W-12V
LPH-18W-12V
Output
- Rated Power: 52.8W
- Rated Current: 2.2A
- DC Voltage: 24V
- Voltage Tolerance: +1.0%
Input
- Voltage Range: 85~264VAC 120-373VDC
- Efficiency (Typ): 88%
- Dimension (mm): 99 x 82 x 30
LRS-75-12V
LPH-18W-12V
LRS-75-12V
Output
- Rated Power: 75W
- Rated Current: 6A
- DC Voltage: 12V
- Voltage Tolerance: +1.0%
Input
- Voltage Range: 85~264VAC 120-373VDC
- Efficiency (Typ): 89%
- Dimension (mm): 99 x 97 x 30
LRS-75-24V
LRS-75-12V
Output
- Rated Power: 75W
- Rated Current: 6A
- DC Voltage: 24V
- Voltage Tolerance: +1.0%
Input
- Voltage Range: 85~264VAC 120-373VDC
- Efficiency (Typ): 89%
- Dimension (mm): 99 x 97 x 30
LRS-75-24V
Output
- Rated Power: 75W
- Rated Current: 6A
- DC Voltage: 24V
- Voltage Tolerance: +1.0%
Input
- Voltage Range: 85~264VAC 120-373VDC
- Efficiency (Typ): 89%
- Dimension (mm): 99 x 97 x 30
